Scheda tecnica locale

Stage W 5mt x D 4.5 mt x H 0.4 mt   Distance stage – FOH: 5 mt

Microphones

  • 1 BETA 52A (dynamic, supercardiod)
  • 3 Shure SM58 (dynamic, cardiod)
  • 5 Shure SM57 (dynamic, cardiod)
  • 4 Shure PGA 81(condenser, cardiod)
  • 1 Shure GLXD24E (wireless microphone)
  • 2 Audix D2 (dynamic, supercardiod)
  • Audix D4 (dynamic, supercardiod)

P.A.

  • JBL VRX932LA-1WH (line array HF 1.5” – LF 12”, 1600W,   frequency response 75Hz – 20 kHz))
  • JBL STX818S (18” bass reflex sub, 2000W, frequency response 40 Hz -120 Hz) )
  • 1 Crown XTi 6002 amplifier (2100W)
  • 2 Crown XTi 4002 amplifier (1200W)
  • 1 Crown XTi 1002 amplifier (500W)

Stage monitor

  • 1 JBL eon 615 (self powered 15”, two way, bass reflex, frequency response 57Hz- 20kHz), 500 W RMS)
  • 4 JBL eon 612 ( self powered 12”, two way, bass reflex, frequency response 57Hz- 20kHz), 500 W RMS)

Mixer (f.o.h. and stage)

  • Soundcraft Expression 2 (internal dynamics and eq, 4 Lexicon effects)
  • Beheringer DJX900usb (dj consolle)
  • 2 gemini cdj 650

Hardware

  • 4 Beheringer DI 100 D.I. boxes
  • 10 boom microphone stands
  • 2 short microphone stand
  • 24 xlr cables (5metres)
  • 5 xlr (Ultimo cavo) Reference Cable (5metres)
  • 5 Xlr (Ultimo cavo) Reference Cable (10 metres)
  • 10 instrument cables (5metres)
  • 2xlr cable (4mt)
  • stage box 24 inputs – 8 aux returns

Lights

  • 10 par 64 cx – 1 rgbw led par
  • 1 mixer luci Cyber 24
